Serverless Image Classification with Oracle Functions and TensorFlow

Photo by Franck V. on Unsplash

Oracle Functions

What to Expect

Photo by Alan Hardman on Unsplash

The Code

public class LabelImageFunction {
public String classify(byte[] image) { ...
Tensor<String> input = Tensors.create(image); ...
}
}
schema_version: 20180708
name: classify
version: 0.0.1
runtime: java
memory: 1024
timeout: 120
triggers:
- name: classify
type: http
source: /classify
FROM fnproject/fn-java-fdk-build:jdk9-1.0.75 as build-stage
WORKDIR /function
ENV MAVEN_OPTS -Dhttp.proxyHost= -Dhttp.proxyPort= -Dhttps.proxyHost= -Dhttps.proxyPort= -Dhttp.nonProxyHosts= -Dmaven.repo.local=/usr/share/maven/ref/repository
ADD pom.xml /function/pom.xml
RUN ["mvn", "package", "dependency:copy-dependencies", "-DincludeScope=runtime", "-DskipTests=true", "-Dmdep.prependGroupId=true", "-DoutputDirectory=target", "--fail-never"]
ADD src /function/src
RUN ["mvn", "package"]
FROM fnproject/fn-java-fdk:jdk9-1.0.75
WORKDIR /function
COPY --from=build-stage /function/target/*.jar /function/app/
CMD ["com.example.fn.HelloFunction::handleRequest"]
FROM fnproject/fn-java-fdk-build:jdk9-1.0.75 as build-stage
WORKDIR /function
ENV MAVEN_OPTS -Dhttp.proxyHost= -Dhttp.proxyPort= -Dhttps.proxyHost= -Dhttps.proxyPort= -Dhttp.nonProxyHosts= -Dmaven.repo.local=/usr/share/maven/ref/repository ADD pom.xml /function/pom.xml
RUN ["mvn", "package", "dependency:copy-dependencies", "-DincludeScope=runtime", "-DskipTests=true", "-Dmdep.prependGroupId=true", "-DoutputDirectory=target", "--fail-never"]'
ARG TENSORFLOW_VERSION=1.12.0
RUN echo "using tensorflow version " $TENSORFLOW_VERSION RUN curl -LJO https://storage.googleapis.com/tensorflow/libtensorflow/libtensorflow-$TENSORFLOW_VERSION.jar
RUN curl -LJO https://storage.googleapis.com/tensorflow/libtensorflow/libtensorflow_jni-cpu-linux-x86_64-$TENSORFLOW_VERSION.tar.gz RUN tar -xvzf libtensorflow_jni-cpu-linux-x86_64-$TENSORFLOW_VERSION.tar.gz
ADD src /function/src
RUN ["mvn", "package"]
FROM fnproject/fn-java-fdk:jdk9-1.0.75
ARG TENSORFLOW_VERSION=1.12.0
WORKDIR /function
COPY --from=build-stage /function/libtensorflow_jni.so /function/runtime/lib
COPY --from=build-stage /function/libtensorflow_framework.so /function/runtime/lib
COPY --from=build-stage /function/libtensorflow-$TENSORFLOW_VERSION.jar /function/app/
COPY --from=build-stage /function/target/*.jar /function/app/
CMD ["com.example.fn.LabelImageFunction::classify"]

Deploying to Oracle Functions

curl -LSs https://raw.githubusercontent.com/fnproject/cli/master/install | sh
api-url: https://functions.us-phoenix-1.oraclecloud.com oracle.compartment-id: <OCI_compartment_OCID>
oracle.profile: <profile_name_in_OCI_config>
provider: oracle
registry: <OCI_docker_registry>
[DEFAULT]
user=ocid1.user.oc1..exampleuniqueID fingerprint=20:3b:97:13:55:1c:5b:0d:d3:37:d8:50:4e:c5:3a:34 key_file=~/.oci/oci_api_key.pem tenancy=ocid1.tenancy.oc1..exampleuniqueID pass_phrase=tops3cr3t region=us-ashburn-1
[ORACLE_FUNCTIONS_USER]
user=ocid1.user.oc1..exampleuniqueID fingerprint=72:00:22:7f:d3:8b:47:a4:58:05:b8:95:84:31:dd:0e key_file=/.oci/admin_key.pem tenancy=ocid1.tenancy.oc1..exampleuniqueID pass_phrase=s3cr3t region=us-phoenix-1
fn use context <context_name>
git clone https://github.com/abhirockzz/fn-hello-tensorflow
fn create app <app_name> --annotation oracle.com/oci/subnetIds='["<subnet_ocid>"]'
fn create app fn-tensorflow-app --annotation oracle.com/oci/subnetIds='["ocid1.subnet.oc1.phx.exampleuniqueID","ocid1.subnet.oc1.phx.exampleuniqueID","ocid1.subnet.oc1.phx.exampleuniqueID"]'
fn deploy --app <app_name>
fn -v deploy --app fn-tensorflow-app
<dependency>
<groupId>org.tensorflow</groupId> <artifactId>tensorflow</artifactId>
<version>1.11.0</version>
<scope>provided</scope>
</dependency>
fn -v deploy --app fn-tensorflow-app --build-arg TENSORFLOW_VERSION=<version>
fn -v deploy --app fn-tensorflow-app --build-arg TENSORFLOW_VERSION=1.11.0

Time to Classify Images!

cat <path to image> | fn invoke fn-tensorflow-app classify
cat /Users/abhishek/manwithhat.jpg | fn invoke fn-tensorflow-app classify
“366 • 9 • Gringo” (CC BY-NC-ND 2.0) by Pragmagraphr
This is a ‘sombrero’ Accuracy — 92%
cat /Users/abhishek/terrier.jpg | fn invoke fn-tensorflow-app classify
“Terrier” (CC BY-NC 2.0) by No_Water
This is a 'West Highland white terrier' Accuracy - 88%

Summary

--

--
